Outdoor Power Pedestal, 2-Gang Device Plate with Hinged Cover

XPP2G30C-BK Wiremold
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getAggregateRating, 3ms
  • REVIEWS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

Outdoor Power Pedestal with Cover

Color Black
Number of Channels 1
Number of Gangs 2 Gang
  • Send
  • Save as PDF
  • Add to favorites Remove from favorites

Features

  • The outdoor power pedestal is a durable solution for high amperage applications (15-60A).
  • Pedestal can be used to provide power for outdoor equipment, food trucks, and other events.
  • Available in several versions to accommodate 1-gang, 2-gang or pin and sleeve devices.
  • Unit is also available with a divider for 2-gang applications to enable low voltage along with power.
  • Standard height is 30" but custom heights are available.
  • Durable sheet-metal construction and outdoor-rated paint stands up to weather conditions and harsh environments.
  • Pedestal does not include devices. Included cover can be used to protect 15-20A weather-resistant devices. 30-60A devices must be watertight.
  • Cover also includes locking mechanism to keep connections secure.

Specifications

General Info
Product Line Wiremold
Color Black
UPC Number 786776194791
Country Of Origin United States
Application Sector Commercial
Dimensions
Product Width US 3.0 in
Product Height US 30.0 in
Product Length US 6.0 in
Listing Agencies / 3rd Party Agencies
cULus Listed  Yes
Technical Information
Seismic Tested No
Number of Gangs 2
Indoor/Outdoor Both

Reviews

  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 3ms
  • REVIEWS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

Questions & Answers

Is there a model that allows for (2) 30A Receptacles NEMA 5-30R, in one pedestal?

Asked by: Mike
Hi, No. Two separate pedestals would be required. Thanks,
Answered by: Wiremold Tech Support
Date published: 2024-09-30

What is the footing size required for the pedestal?

Asked by: clayton
Hello, The Outdoor Power Pedestal will fit on any standard concrete tube diameter (8", 10" or 12") and the stud anchors provided only require a minimum of 2 inches of concrete. Thank you
Answered by: Wiremold Tech Support
Date published: 2024-09-30

Is the model XPP1G30C (30"H) ADA compliant in terms of opening and closing the cover ? Does the cover stays in open position for a person with disability to use?

Asked by: amanuel
Hi, No that cover would not stay in an open position without it physically being held up. Thanks,
Answered by: Wiremold Tech Support
Date published: 2024-06-11

Can this pedestal be used for rv parks?

Asked by: lneck30
It may be possible, but to confirm we need more details about the conditions it will be used under and the type of outlets you need to install in it. For a question like this, it's best to contact Legrand Wiremold Technical Support by phone. Please contact 1-844-95-SERVE (1-844-957-3783). Choose 2 for Wiremold, then press 2 again for Technical Support .
Answered by: Wiremold Tech Support
Date published: 2021-10-22

warranty for Power Pedestal #XPP2G30CD-SV?

Asked by: bill
Hello- The Wiremold Company (Wiremold) warrants, to the original purchaser or owner only, that any product manufactured and sold by Wiremold will be substantially free from defects in material and workmanship under normal use and service, for a period of one year from the date of original installation or two years from the date of purchase, whichever is sooner. This limited warranty applies only to products, which have been installed properly in accordance with installation instructions supplied by Wiremold and any applicable codes and standards. A full listing of the Wiremold Limited Warranty & Liability Statement as well as the products covered can be found on the attached document. https://legrand.my.salesforce.com/sfc/p/80000000JuWx/a/0h0000005ZTf/AznR6w0Yij9Gtms2Kg9UIqvKzfbAyi5G7j1x7SnL8Gs URL NAME Additional-Wiremold-Product-Warranty
Answered by: Wiremold Tech Support
Date published: 2021-09-02

This brochure indicates that there are custom height poles available. What is the tallest pole available and what would be the criteria required to get custom poles?

Asked by: RandyCRE
Hello, There are custom options available for the power pedestals. The best suggestion is to reach out to the local Legrand rep in your area for assistance with special ordering. The reps will be able to provide the necessary information with regards to custom ordering. To find the local rep in your area you can follow these steps: Click this link: https://www.legrand.us/where-to-buy (you may have to copy and paste it in your browser window) Select "shop local or find a sales rep" Next, under "where to buy" select "Sales rep" The brand name is "Wiremold" Lastly, under "who are you?" select the best description that describes you. When you hit search it'll provide you with the best point of contact local to you to discuss custom capabilities. Should you have any issues or concerns please fell free to reach out to us directly at 1-844-957-3783, option 2 for Wiremold.
Answered by: Wiremold Tech Support
Date published: 2024-09-30
